High Speed Empty Can Depalletizer Automatic Depalletizing Machine
- application:Apparel, Beverage, Chemical, Commodity, Food, Machinery & Hardware, Textiles, Medical
- packaging type:Cartons, case
- packaging material:Metal, Paper, Plastic
- automatic grade:Automatic
- driven type:Electric
- Voltage:380V
- place of origin:Guangdong, China
- brand name:VANTA
- dimension(l*w*h):4050*2500*4550
- warranty:1 Year
- key selling points:High-Accuracy
- machinery test report:Provided
- video outgoing-inspection:Provided
- core components:Bearing, Motor, Pump, Gear, PLC, Other
- capacity:50000 Cans / Hour
- type:high level
- power:18kw
- Product name:Depalletizer
- Machine type:Vertical Automatic Packing Machine
- Type:Packaging Line
- Applicable Industries:Manufacturing Plant, Food & Beverage Factory, Food & Beverage Shops
- Showroom Location:Canada, Morocco
- Condition:New
- Warranty of core components:1 Year
- Weight:1000
1. Description:
Bulk Can Depalletizer, or Empty Can Depalletizer, is a full automatic and intelligient packaging equipment which is applied to unloading empty cans and putting them onto the conveyer for the next procedure. The depalletizer consists of several main parts, namely, case conveying platform, pallet conveyor, pallet magazine and pallet conveying roller device. This machine is suitable for beer, beverage and foodstuff industries which are aimed at recycling cans in the production line.
2. Equipment datasheet
| Machine Model | XGD300Y |
| Capacity (BPH) | ≥50000BPH |
| Machine position | High level |
| Handle bottle size | Ø50~110mm H70~360mm Full pallet height≤2500mm |
| Standard bottle conveying height | 3300mm |
| Main machine height | 4700mm |
| Pallet conveying height | 600mm |
| Pallet size | 1200*1000*150(L*W*H) |
| Power supply | 3P AC 380V±5%; 50Hz |
| Control voltage | 24V.DC |
| Compressed air | Working pressure 0.40.6Mpa Air consumption 330~550L/min |
| Weight | 10T |
| Total power | 18KW |
| Noise | <85dB |
| Operator | 2 persons |
3. Working environment
3.1 Temperature:Min.+10 º C -Max.+45 º C,Fluctuations in daily working ±3 º C
3.2 Humidity:Max.90%.
3.3 Set according to attitude of 1000 meters
3.4 If the above conditions cannot meet or exceed the size specified in the contract, the customer shall immediately notify the VANTA sales department in order to make the appropriate adjustments to ensure the normal operation of the machine. If the customer fails to notify the sales department. Any caused machine problems, will be customer's responsibility.
4. Competitive Advantage:
4.1 Grip and place in a whole line or whole layer.
4.2 The safety device can stop machine and alarm automatically in any emergency.
4.3 Simple configuration and easy maintenance.
4.4 High automation and intelligence.
4.5 Assuring smooth motion without damaging on empty bottles.
5. Appled Product:
